Rotax 618 exhaust, Rotax 618 exhaust parts

#
Part #
Description
Qty
Req.
1 850 550 Gasket
2
2 979 210 Exhaust manifold w/hooks
1
3 945 751 Lock washer A6
8
4 840 861 Allen screw M6x25,22NM
8
5 950 141 Gasket ring A8x13
 2
6 941 615 Capstan screw M8x1 x10
2
7 973 183 Exhaust elbow w/hooks
1
8 978 840 Muffler assy, sidemount 1
978 845 Muffler assy, eipper  1
9 938 795 Spring 66mm 6
10 853 355 Hook, stainless 12
11 PSAS Anti-seize As Rqd
842 758 Threaded weld on boss for 8mm egt probes, not shown 2

Rotax 618 exhaust, Rotax 618 exhaust parts

Rotax 618 exhaust, Rotax 618 exhaust parts
