Rotax 912 ignition cover,
|
|
|
|
|
Click to visit Excalibur Aircraft. |
|
 |
|
IGNITION COVER, WATER PUMP REV COUNTER & ELECTRIC
| No. |
Part# |
Description |
912UL |
912A |
912F |
912ULS |
912S |
914UL |
914F |
| 1 |
810 617 |
Ignition housing assembly |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
|
810 618 |
Ignition housing assembly |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 2 |
850 965 |
Oil seal 35x52x7 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 3 |
850 977 |
Oil seal A12x30x7 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 4 |
850 945 |
Rotary seal, see SB#4KUL97 |
1c |
1c |
1c |
1c |
1c |
1c |
1c |
| 5 |
837 111 |
Pump shaft |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 6 |
834 135 |
Pump gear 15T |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 7 |
926 273 |
Washer 8.2/12.5/1.5 |
1ac |
1ac |
1ac |
1ac |
1ac |
1ac |
1ac |
| 8 |
922 224 |
Impeller, 15NM |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 9 |
850 981 |
Gasket |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 10 |
922 202 |
Water pump housing |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 11 |
922 232 |
Bent socket, 45 degrees |
4 |
4 |
4 |
4 |
4 |
3 |
3 |
| 12 |
922 230 |
Bent socket, 80 degrees |
1b |
1b |
1b |
1b |
1b |
1 |
1 |
| 13 |
945 751 |
Lock washer, A6 |
13 |
13 |
13 |
13 |
13 |
13 |
13 |
| 14 |
241 481 |
Allen screw M6x90, 10NM |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 15 |
241 811 |
Allen screw M6x35, 10NM steel |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 16 |
230 415 |
Gasket ring A 6x10 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 17 |
241 813 |
Allen screw M6x35, 10NM stainless |
1a |
1a |
1a |
1a |
1a |
1a |
1a |
| 18 |
230 020 |
O ring 32x2 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 19 |
922 214 |
Water inlet, new |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 20 |
241 930 |
Allen screw M6x20, 10NM |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 21 |
230 880 |
O ring 13.3-2.4 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 22 |
810 620 |
Cover plate |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 23 |
945 750 |
Lock washer A5 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 24 |
840 511 |
Allen screw M5x16 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 25 |
837 150 |
Rev counter shaft |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 26 |
912 190 |
Rev counter housing |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 27 |
930 500 |
Oil seal 6x11x3.4/5 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 28 |
840 880 |
Allen screw M6x30, 10NM |
7 |
7 |
7 |
7 |
7 |
7 |
7 |
| 29-34 |
296 152 |
Electric starter |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 30 |
840 635 |
Stud M5x160/16 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 31 |
850 510 |
O ring 4.7x1.4 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 32 |
847 249 |
Distance sleeve, 5.4/10/11 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 33 |
927 571 |
Washer 5.3 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 34 |
945 750 |
Lock washer A5 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 35 |
242 071 |
Hex nut M5 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 36 |
851 020 |
Clamp 76 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 37 |
992 319 |
Starter relay assembly |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 38 |
945 751 |
Lock washer A6 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 39 |
242 211 |
Hex nut M6 |
2 |
2 |
2 |
2 |
2 |
2 |
2 |
| 40 |
960 719 |
Connector sheath |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| 41 |
864 011 |
Faston connector 6.3x.8 |
1 |
1 |
1 |
1 |
1 |
1 |
1 |
| a |
Stainless |
| b |
Optional for engine
suspension frame |
| c |
The rotary seal was
introduced from following serial#. Up to this serial#, the rotary seal has
to be exchanged together with part# 850 945, 926 273, 922 224. |
|
912UL |
4403283 |
|
912A |
4410366 |
|
912F |
4412791 |
|
914UL |
4417783 |
|
914F |
4420157 |
|
|
|
|
|
|
|
